Description
The LZBE is a fully laser-welded miniature load cell for tension and compression force measurements. It is suitable for compact test setups, machine monitoring, assembly systems and applications with limited installation space.
The load cell is available in measuring ranges from 500 N to 5,000 N or 50 kg to 500 kg. The total error is at most ±0.22 % FS.
The housing is made of 17-4PH / 1.4542 stainless steel and, with IP68 protection, is particularly well protected against external influences. A high-temperature version up to +250 °C, ISO 17025 calibration and matching rod ends are available as options.
Benefits at a glance
- Miniature load cell for tension and compression
- Measuring ranges from 500 N to 5,000 N
- Total error ≤ ±0.22 % FS
- Stainless steel housing made of 17-4PH / 1.4542
- IP68 protection
- Fully laser-welded
- Suitable for dynamic measurements
- Optionally available with rod ends
