Description
The LKBA is a compact, button-type, compression load cell made of aluminum alloy with high input resistance for space-saving installation situations. It is suitable for OEM integrations, test benches, and applications with limited installation space.
The load cell is available in measuring ranges from 0.5 kN to 5 kN or 50 kg to 500 kg. The total error is a maximum of ±0.15% FS.
The housing is made of aluminum alloy and has an IP64 protection rating for industrial operating conditions. An ISO 17025 calibration is optionally available.
Advantages at a glance
- Compact, button-type compression load cell
- Measuring ranges from 0.5 kN to 5 kN
- Total error ≤ ±0.15% FS
- Aluminum alloy housing
- Protection rating IP64
- High input resistance for space-saving integration
- Optionally with ISO 17025 calibration
