Bending beam and shear beam load cells L-FTP

Bending beam and shear beam load cells L-FTP are characterized by their diverse areas of application.

The hermetically sealed welded bellows with protection class IP67/IP68 allows use even under harsh operating conditions. The bending beam load cells are made of nickel-plated, alloyed stainless steel and are characterized by high accuracy , linearity and high stability. Our bending beam load cells are also available with weighing modules.

Features of L-FTP bending beam and shear beam load cells

✅ Bending bar : Designed for nominal loads from 75 kg to 300 kg

✅ Shear beam : Designed for nominal loads from 500 kg to 10000 kg

✅Combined animal error <±0.02%

✅Material: stainless steel AISI 420

✅ OIML R60 C3 certified, ATEX II 1GD, IECEx, IP69K optional

✅Particularly robust for tough continuous use in the industrial sector

✅Compatible with other manufacturers

data sheet

CAD model:
L-FTP 75|150|300kg
L-FTP 500|750|1000|1200|1500|2000kg
L-FTP 3000|5000kg
L-FTP 10000kg
