Description
The QZKH is an oval gear flowmeter with a mechanical counter and flanged connection for nominal sizes from DN10 to DN200. It is particularly suited to measuring points without auxiliary power, since it counts without a supply; an electrical output is available as an accessory.
Positive displacement, two oval gears drive the counter through a gear train, no straight inlet run needed. Flow range from 0.03 at DN10 to 340 at DN200, given without a unit in the sheet. Accuracy class 0.5 or 0.2, depending on viscosity; repeatability is not documented. Reading on the mechanical counter or an electronic counter. Optional photoelectric pulse transmitter, three-wire, 12 or 24 V, or a 4 … 20 mA transmitter without stated supply, load or accuracy.
Five material versions: cast iron, cast steel, cast iron with aluminium-alloy gears, stainless steel throughout, and aluminium alloy as lightweight version; nominal pressure 1.6 · 2.5 · 4.0 · 6.3 MPa by model. Working temperature -10 … +60 °C, ambient -40 … +50 °C. The protection grade is not documented. Explosion protection per the sheet 'Ex d IIB T4', without certificate, group or category. A declaration of conformity is not documented in the datasheet. Before sizing, note: the flow tables carry no unit; only the questionnaire speaks of m³/h. A medium temperature is stated nowhere and the statements on the high-temperature version contradict each other. The nominal pressure depends on model and size and departs from the steps with 4.1 MPa for cast steel at DN80 … DN100.
Advantages at a glance
- Mechanical counter, works without power
- Flanged connection DN10 … DN200
- Accuracy class 0.5 or 0.2
- Five material versions from cast iron to stainless steel
- No straight inlet run needed
- Pulse or 4 … 20 mA output as accessory
- Heating jacket for media that solidify
- Ambient temperature -40 … +50 °C
